100 Meter (MOQ)
| Business Type | Manufacturer, Exporter, Supplier |
| Product Type | Single Core Cable |
| Conductor Material | Electrolytic Grade Copper |
| Construction | Solid / Single Stranded / Multi Stranded |
| Click to view more | |
Product Details
Single Core Cables are electrical wires consisting of a single conductor insulated with plastic, polymer, or rubber materials. These cables are manufactured in solid, single-stranded, multi-stranded, or braided constructions to suit different wiring needs.
A single solid wire contains one continuous metal conductor, while stranded wires are made by bundling multiple fine wires together to form a larger, more flexible conductor. Based on application requirements, single core cables can also be manufactured in round, square, or flat shapes.
These cables are widely used for safe and efficient electrical wiring in residential and commercial buildings.
Types of Single Core Cables-
PVC Insulated Single Stranded Wire
-
PVC Insulated Multi Stranded Wire
-
FR – up to 90°C
-
FRLS – up to 105°C
-
HFFR – up to 120°C
Technical Data
| Single core PVC insulated bare copper conductor unsheathed 1.1 KV cable wire | ||||
| Nominal Area (Sq. mm.) | Insulation Thickness (mm) | Outer Diameter (Approx) | Current Rating (Amps) | Max. DC Resistance Ohm/Km at 20°c |
| 0.5 | 0.6 | 2.1 | 4 | 39 |
| 0.75 | 0.6 | 2.27 | 7 | 26 |
| 1 | 0.6 | 2.44 | 12 | 19.5 |
| 1.5 | 0.6 | 2.66 | 16 | 13.3 |
| 2.5 | 0.7 | 3.27 | 22 | 7.98 |
| 4 | 0.8 | 3.99 | 29 | 4.95 |
| 6 | 0.8 | 4.52 | 37 | 3.3 |
| 10 | 1 | 5.9 | 51 | 1.91 |
| 16 | 1 | 7 | 68 | 1.21 |
| 25 | 1.2 | 8.77 | 86 | 0.78 |
| 35 | 1.2 | 9.67 | 110 | 0.55 |
| 50 | 1.4 | 11.44 | 145 | 0.39 |
| 70 | 1.4 | 13.44 | 215 | 0.27 |
| 95 | 1.6 | 15.46 | 260 | 0.21 |
| 120 | 1.6 | 17.16 | 305 | 0.16 |
| 150 | 1.8 | 19.08 | 355 | 0.13 |
| 185 | 2 | 21.2 | 415 | 0.11 |
| 240 | 2.2 | 24.12 | 500 | 0.08 |
| 300 | 2.4 | 27.04 | 585 | 0.06 |
| 400 | 2.6 | 30.5 | 695 | 0.05 |
| 500 | 2.8 | 34.96 | 790 | 0.04 |
| 630 | 2.8 | 37.98 | 905 | 0.03 |
| 800 | 3.2 | 43.72 | 1050 | 0.02 |
| 1000 | 3.2 | 47.72 | 1185 | 0.02 |
